JBL Stage GT 60041 4-Channel 65 W × 4 Amplifier
Class-D four-channel Stage GT with start/stop compatibility
$229.95
Overview
Stage GT 60041 is a compact Class-D four-channel amplifier rated 65 W RMS × 4 at 4 ohms, 90 W × 4 at 2 ohms, or 180 W × 2 bridged at 4 ohms. Variable 32–320 Hz crossovers, 0–12 dB bass EQ at 45 Hz, wide input sensitivity, OEM load detect, and start/stop compatibility support factory upgrades. Start/stop compatibility and OEM load detect help the amp behave with newer factory radios. Speaker-level inputs cover 1–25 V.
Product details
Stage GT four-channel power
Sixty-five watts RMS per channel at 4 ohms gives coaxials and components clear headroom. Bridge pairs when a door needs more voltage. Mount the chassis to solid metal with the supplied hardware and keep cooling fins in free air. Size power and ground cable for the fuse rating, and set input sensitivity with a multimeter or oscilloscope after the speakers are connected.
Modern vehicle friendly
Start/stop compatibility and OEM load detect help the amp behave with newer factory radios. Speaker-level inputs cover 1–25 V. Mount the chassis to solid metal with the supplied hardware and keep cooling fins in free air. Size power and ground cable for the fuse rating, and set input sensitivity with a multimeter or oscilloscope after the speakers are connected.
Protection and fusing
On-board protection covers shorts, over/under voltage, over-current, and over-temperature. Fuse rating 20 A × 2. Mount the chassis to solid metal with the supplied hardware and keep cooling fins in free air. Size power and ground cable for the fuse rating, and set input sensitivity with a multimeter or oscilloscope after the speakers are connected.
Key features
- 4-channel Class-D amplifier
- 65 W RMS × 4 @ 4 Ω
- 90 W RMS × 4 @ 2 Ω
- 180 W RMS × 2 bridged @ 4 Ω
- Variable HP/LP filters 32–320 Hz
- Bass EQ 0–12 dB @ 45 Hz
- Start/stop compatible
- OEM load detect compatible
- Fuse 20 A × 2
Specifications
| Brand | JBL |
|---|---|
| Model | Stage GT 60041 |
| SKU | STAGE60041 |
| UPC | 050036412766 |
| Product type | 4-channel amplifier |
| Power @ 4 Ω | 65 W RMS × 4 |
| Power @ 2 Ω | 90 W RMS × 4 |
| Bridged @ 4 Ω | 180 W RMS × 2 |
| Max power | 1240 W peak |
| Frequency response | 20 Hz – 20 kHz ±1 dB |
| Crossover | 32–320 Hz variable |
| Bass EQ | 0–12 dB @ 45 Hz |
| Fuse | 20 A × 2 |
| Start/stop | Compatible |
| Channels | 4 channel |
Important notes
- Power and ground cable not included — size for the fuse rating.
- Mount with airflow around the extruded aluminum chassis.
What's in the box
- 1x Amplifier
- 2x Spare fuses
- 1x High-level input cable
- 4x Mounting screws with washers
- 2x Allen keys
- 2x JBL stickers
- 1x QR code owner manual
- 1x Safety sheet
